DLA-12-10-A-200-HS2-IP65

$262.20
$221.90
$191.30
$127.30
Quantity:

In stock

Compact linear actuator. Select between 12 and 24 V, most gear ratios and stroke lengths. Integrated limit switch. Position sensor as option: potentiometer or pulse sensor.

Print
Maximum force300 N
Voltage12 V
Current at maximum load3 A
Speed at maximum load25 mm/s
EncoderYes
Limit switchYes
Stroke length200 mm
Duty cycle25%
Weight

1.33 kg

SKU

16012214
