PD1230-2.4-16-FE
PD1230-2.4-16-FE
≥ 1 pcs
€204.80
≥ 5 pcs
€129.80
≥ 25 pcs
€68.20
≥ 50 pcs
€59.90
≥ 100 pcs

Available on backorder

  • Specification
  • Customizations
  • Datasheet and downloads
Voltage
2.4 V
Diameter
12 mm
Power
0.62 W
Profile
Circular
Length
16.1 mm
Nominal speed
600 rpm
Nominal torque
6.9 mNm
Current at maximum load
0 A
Weight
0.0292 kg
SKU
10331202
Some of the possible customizations:
Shaft length
Shaft profile
Connectors
Cabling
Gear & pinion material
Operating temperature
For any inquiries regarding customizations, please contact us at:
Catalog
Datasheet
3D CAD (.stp)
