DLA-12-10-A-200-POT-IP65

$297.30
$250.80
$218.60
$145.30
Quantity:

In stock

Compact linear actuator. Select between 12 and 24 V, most gear ratios and stroke lengths. Integrated limit switch. Position sensor as option: potentiometer or pulse sensor.

Print
Maximum force300 N
Voltage12 V
Current at maximum load3 A
Speed at maximum load25 mm/s
PotentiometerYes
Limit switchYes
Stroke length200 mm
Duty cycle25%
Weight

1.76 kg

SKU

16012114
