Linear actuator 12VDC 56.2lbf 2.4A
Product name: DLA-12-10-A-25-HS2-IP65 | SKU: 16212210
Linear actuator for direct current with voltage 12VDC force 56.2lbf current 2.4A. The actuators include a range with supply voltages between 12-24V and can, depending on the type, be supplied with encoder, potentiometer and adjustable limit switches. Accessories for mounting are sold separately. All actuators can be customized as needed. Common adjustments are stroke length, cable connections and cabling. Read more here about customizations and please contact us for further information.
≥ 1 pcs
$250.30
≥ 5 pcs
$210.80
≥ 25 pcs
$182.70
≥ 50 pcs
$121.30
≥ 100 pcs

In stock

Voltage
12VDC
Nominal current
2.4A
Feedback
Hall sensor
Maximum Force
56.2lbf
Speed at maximum load
0.93in/s
Stroke length
1in
Weight
28.22oz
SKU
16212210
Some of the possible customizations:
For any inquiries regarding customizations, please contact us at:
